Joint demonstration of 3D optical inspection solution

28 September 2022

We are excited to share a recent collaborative demonstration for the US Navy at ANTX Coastal Trident. For this project, we joined forces with Voyis Imaging Inc., producers of underwater laser scanners and imaging systems for subsea surveys and inspections, and Sonardyne, producers of highly accurate positioning systems, two of our sister companies in Covelya Group.

This demonstration brought together an advanced 3D optical inspection solution using EIVA’s NaviSuite Mobula ROV control and inspection software for steering, as well as acquisition and visualisation of data collected with Voyis’ Perception ROV skid attached to VideoRay’s Mission Specialist Defender ROV. The solution has the focus of identifying mine-like-objects (MLOs) during mine countermeasure operations.  Additionally, Sonardyne demonstrated the Initiation Transponder (IT 6) to highlight safe and remote neutralization of the identified target.

Automated runline planning of the demo in NaviSuite Mobula ROV inspection software

Subsea techologies involved

Software for ROV automation and data visualisation

EIVA’s NaviSuite Mobula is a plug-and-play ROV control and inspection software, allowing operators to plan and perform inspections efficiently, while also enabling automation. This software allows users to control various ROV models and leverage advanced sensors. Additionally, it provides high-performing features focusing on automated steering and inspection, as well as delivering advanced, high-quality data visualisations.

NaviSuite Mobula ROV software displaying camera feed, map and positioning

Skid and payload for survey-grade 3D inspections

Voyis’ Perception skid is a survey-grade 3D inspection solution that delivers real-time dense 3D modelling and image mapping from smaller ROV platforms.  The skid includes Voyis’ industry leading underwater laser scanning technology and 4K digital stills imaging package, tightly coupled with Sonardyne’s SPRINT-Nav Mini positioning solution to create accurate, georeferenced results for true representation of subsea assets.

Watch this video showing the demo the total solution demonstrated includes the optical payload and skid from Voyis, positioning from Sonardyne and software for ROV steering, data processing and delivery from EIVA

VideoRay’s Mission Specialist Defender is an observation class ROV designed for more precise control of the vehicle position and orientation, heavier payloads, and demanding intervention, such as rendering unexploded ordnance safe or cleaning nets for offshore fish farms.

Sonardyne’s Initiation Transponder 6 (IT 6) is designed to be connected directly to a remotely deployed, non-electric mine neutralisation device allowing commercial and naval EOD teams to send a wireless, acoustic command from their vessel to initiate a shock tube. It can be placed directly by a clearance diver or remotely operated vehicles (ROVs).

Solution results in greater resolution plus control and actionable analysis

Data obtained from the Perception skid onboard the Defender will allow for a higher quality of data to be collected for qualitative and quantifiable analysis of subsea targets, structures/assets and seabed. Coupling the greater resolution with vehicle control, data acquisition and actionable analysis using EIVA’s NaviSuite software interface will provide a tighter integration between hardware and software, offering a completely tailored customer experience.

The partnership has received its first confirmed order of the solution, where the customer will take possession of the offering in Q3 2022.

The beautiful location of this demo

About Voyis

Voyis, founded in 2007, is the first company to widely provide underwater laser scanners for underwater surveys and inspection.  Voyis’ focus is to provide versatile optical solutions that expand customers’ underwater capabilities and help enhance understanding of remote or challenging environments by producing the best data possible.

About Sonardyne

Sonardyne, founded in 1971, is recognised as a world leader in the design and manufacture of underwater acoustic positioning, inertial navigation, wireless communications and sonar technologies and services for the offshore energy, defence and science sectors.

About EIVA

EIVA, formed in 1978, provides software, equipment, and integrated system solutions to maritime customers across the world. EIVA’s proven and reliable tools support everything from underwater exploration, oceanography and hydrographic surveying to offshore construction, cable laying, dredging and rig operations.

About VideoRay

VideoRay is a global leader in Underwater ROV (Remotely Operated Vehicles) technology. Established in 1999, VideoRay has worked with technology and mission partners around the world to develop and prove the ROV a tool for a wide range of applications.
