NaviModel 4.0 Patch Test Essentials

NaviModel 4.0 Patch Test Essentials

NaviModel 4.0 Patch Test Essentials eLearning module

The focus of the NaviModel 4.0 Patch Test Essentials eLearning module is to teach the user how to calibrate a multi-beam echo sounder using NaviModel Patch Test.

The module covers the following topics:

  • The purpose of a patch test calibration
  • Patch test planning of survey lines and sequences in processing
  • Patch testing in NaviModel, (excl the preparation of the data (in NaviEdit), as well as the cleaning conducted in NaviModel (S-CAN/EC-3D)).
  • The principles of data collection and post-processing (sequence, calculation method, iterations, etc) and patch test calibration with single head as well as dual head spreads
  • The module ends with a quiz.

Upon completion of the module, the user will be capable of defining a survey plan for the acquisition of the patch test data (both for single head and for dual head scenarios), and conduct a patch test calibration (single head and dual head). The user will furthermore be able to evaluate the calibration results and subsequently implement these results in acquisition as well as post-processing scenarios (in NaviEdit, as well as in NaviScan).

Estimated duration: 2.5 hours, including a quiz after which you can print a certificate with your score.
