NaviSuite processing with pipe/cable inspection
- Conducted by:
- EIVA
- Product no :
- 20240978
- Underwater inspections and surveys
- Cable, pipe and asset inspections
- Hydrography and geophysics
- USV- and vessel-based hydrographic inspections
- Harbour inspections
- Geophysical surveys
- Maritime constructions
- Ocean science and archeology
- Oceanography
- Navigation aid
4-7 Feb 2025 Virtual training
Venue & Language
The course will be held virtually, via Microsoft Teams and will be conducted in English
Duration and timing
The duration of the course is four days with training of the group taking place from 09.00 - 13.00 GMT+1 (CET timezone) and the instructor being available for individual assistance and guidance in solving the excercices that are given from 13:30 - 16:00 GMT+1
The instructor will invite the participants to a half-hour pre-training meeting prior to the start of the course to ensure that all participants are aligned on the process, have met the eLearning requirements and have the software correctly installed and activated
Entry requirement
Attendance at the NaviSuite learning training courses presupposes that participants have passed the required EIVA eLearning modules (with a score of 80% in the quizzes) prior to the start of the course. We recommend that the remaining modules are passed either before or after the course
EIVA eLearning modules to be passed (score of 80%) prior to attending the training course are underlined in the list below
- EIVA Geodesy
- Geodesy
- NaviEdit 8
- NaviEdit 8.5
- NaviModel 4
- NaviModel 4.0 Patch Test
- NaviModel 4.0 (Part 1)
- NaviModel 4.0 (Part 2)
- NaviModel 4.2 Pipeline Inspection
EIVA eLearning
Access to EIVA eLearning for 30 days is incl. in the course fee to allow the participant to prepare for the course and continued access for an additional 12 months can be purchased at the reduced price of €120 if purchase is made before the free EIVA eLearning account expires
Training days
Day 1 - 2: NaviEdit Pro
Day 3 - 4: NaviModel Producer + 3D-Pipeline inspection option
Learning objectives
The virtual course is structured around a general curriculum to give the training course participants a broad understanding of the EIVA NaviSuite processing and reporting software solutions, and to make them confident in carrying post-processing of pipeline and cable inspection data
The training consists of case-based training sessions, in which an instructor will guide the participants through a series of hands-on training scenarios based primarily on the knowledge acquired from the eLearning modules and combined with a short introduction to each main topic by the instructor
During the course, participants are guided through how to:
- Install the relevant NaviSuite software packages
- Conduct editing of multi-beam and single beam echo sounder data in a NaviEdit/NaviModel environment
- Integration of pipe/cable tracker data
- Kalman filtering of USBL data and integration of INS
- Use the EC-3D automatic cleaning tool
- Use the various DTM tools in NaviModel
- Conduct volume and area calculations in NaviModel
- Use video and still image integration in NaviModel
- Use the pipeline inspection tools in NaviModel
- Use eventing in NaviModel
- Export data from NaviModel using user-configurable as well as built-in tools
Target group
The course is a blended training course, which means that specified EIVA eLearning modules must be passed prior to the start of the course
The course is furthermore aimed at both surveyors who have some experience with offshore survey work but also at people with less experience but preferably with a basic knowledge of hydrographic surveying
Certificate
An EIVA NaviSuite training certificate is issued to each trainee upon completion of the course
Access to NaviSuite
EIVA NaviSuite can be downloaded from our website for preparation purposes and can partially run in demo/simulation mode. Activation codes for full access and activation of the NaviSuite software bundle Nardoa is provided for 30 days as part of the course
Technical information
The participant must have a stable internet connection to run Microsoft Teams smoothly
- Minimum PC specifications:
- OS Windows PRO Edition 10 or 11
- 8 GB Ram as a minimum
- 20 GB disk space
- Graphics board 1GB Ram
- The user must have administrative rights over the PC
- Other requirements:
- A mouse with scroll function
- A headset
- 2 x monitors (one to view the training and one to perform the tasks)
- Internet connection via LAN is recommended to avoid fluctuations in the connection
- Further details about the hardware and software specs can be found here
Securing your seat
There is room for up to 8 participants at our virtual training courses and your seat is secured once we have received your payment. We only accept orders that are paid by credit card in our webshop
For further information, please do not hesitate to reach out
