NaviSuite NaviPac configuration and operation

Venue & Language

The course will be held virtually, via Microsoft Teams and will be conducted in Portuguese

​Duration and timing

The duration of the course is four days with training of the group taking place from 08.30 - 14.30 UTC-3 with assigned time for exercises and assistance from 15:00 - 16:00

The instructor will invite the participants to a half-hour pre-training meeting prior to the start of the course to ensure that all participants are aligned on the process, have met the eLearning requirements and have the software correctly installed and activated

Entry requirement

Attendance at the NaviSuite learning training courses presupposes that participants have passed the required EIVA eLearning modules (with a score of 80% in the quizzes) prior to the start of the course. We recommend that the remaining modules are passed either before or after the course

EIVA eLearning modules to be passed (score of 80%) prior to attending the training course are in the list below

• NaviPac 4
  • NaviPac 4.0 Configuration
  • NaviPac 4.1 Helmsman’s Display
  • NaviPac 4.2 Helmsman’s Display Runlines and Waypoint
  • NaviPac LogData
  • NaviPac DataMon

Recommended EIVA eLearning module:

• EIVA Geodesy
  • Geodesy

EIVA eLearning

Access to EIVA eLearning for 30 days is incl. in the course fee to allow the participant to prepare for the course and continued access for an additional 12 months can be purchased at the reduced price of €140 if purchase is made before the free EIVA eLearning account expires

Training days

Day 1 - 2: NaviPac Pro
Day 3 - 4: Helmsman's Display (HMD)

Learning objectives

The virtual course is structured to provide participants with a solid understanding of EIVA NaviSuite software solutions for survey planning, navigation, and data acquisition. Participants learn how to configure and deploy survey sensors during vessel mobilization, manage subsea navigation operations, and monitor and log survey data using NaviPac and Helmsman Display.

Through a series of realistic, case-based exercises, participants gain practical experience with project planning, waypoint and line planning, instrument configuration, data logging, and operational monitoring. The training also develops an understanding of georeferenced situational awareness in both 2D and 3D environments, enabling participants to confidently support and execute offshore survey operations. Hands-on sessions are guided by an instructor and supplemented by eLearning modules that introduce the key concepts and workflows covered throughout the course.

Throughout the training, participants will:

• Build confidence in planning and executing marine survey operations using NaviPac and Helmsman Display.
• Learn to configure, deploy, and manage survey sensors and navigation systems during vessel mobilization and offshore operations.
• Develop practical skills in project setup, waypoint and line planning, instrument integration, and survey data logging.
• Gain an understanding of georeferenced situational awareness and operational monitoring in both 2D and 3D survey environments.
• Apply best practices through hands-on exercises and real-world operational scenarios, including troubleshooting and workflow optimization.

Agenda

The agenda of the course covers:

• NaviSuite general introduction​

• NaviPac introduction​
  • Installation & licence activation
  • General concepts, software overview
  • Project settings & Geodesy
  • Vehicle & instrument configuration
  • Vessel and subsea navigation objects

• NaviPac online
  • Overview & main toolbar
  • Calibration overview & position fix
  • Data monitor & QC
  • Data logging

• ​Helmsman’s Display (HMD)
  • Waypoints, lines & runlines
  • Alarms, Confinement and Exclusion zones
  • Data & map views
  • Vehicle control
  • Video interface & recording
  • Eventing

Target group

The course is a blended training course, which means that specified EIVA eLearning modules must be passed prior to the start of the course

The course is furthermore aimed at both surveyors who have some experience with offshore survey work but also at people with less experience but preferably with a basic knowledge of hydrographic surveying

Certificate

An EIVA NaviSuite training certificate is issued to each trainee upon completion of the course

Access to NaviSuite

EIVA NaviSuite can be downloaded from our website for preparation purposes and can partially run in demo/simulation mode. Activation codes for full access and activation of the NaviSuite software bundle Nardoa is provided for 30 days as part of the course

Technical information

The participant must have a stable internet connection to run Microsoft Teams smoothly

• Minimum PC specifications:
  • OS Windows PRO Edition 10 or 11
  • 8 GB Ram as a minimum
  • 20 GB disk space
  • Graphics board 1GB Ram
  • The user must have administrative rights over the PC

• Other requirements:
  • A mouse with scroll function
  • A headset
  • 2 x monitors (one to view the training and one to perform the tasks)
  • Internet connection via LAN is recommended to avoid fluctuations in the connection

• Further details about the hardware and software specs can be found here

Registration, payment, and course confirmation

Registration for instructor‑led training courses closes 5 days prior to the course start date

Your seat is secured once payment has been received. Our open training courses have a maximum of 8 participants, and registrations are confirmed on a first‑come, first‑served basis. Payment for open courses must be completed by credit card via the EIVA webshop, as only prepaid orders are accepted

Please note that all courses are subject to cancellation if the minimum number of participants is not reached. EIVA reserves the right to cancel a course if fewer than four participants are registered. In the event of a cancellation, all registered participants will be notified shortly after the registration deadline.

For further information, please do not hesitate to reach out
